Lutron CM-6155F DCA/ACA CLAMP METER, Smart, 1,000 A

Lutron CM-6155F DCA/ACA CLAMP METER, Smart, 1,000 A

Features
DCA/ACA CLAMP METER
Model : CM-6155F
* V : Smart ACV/DCV Automatically.
* Resistance, Diode, Continuity, Capacitance. Automatically.
* 600A : Smart DCA/ACA
. * 1000A : Smart DCA/ACA.
* Temp. ( type K ) : -4 oF to 1382 oF. * Function keys : Select, Zero, Hz, Max/Min, Range, Hold.
* CAT III 1000V, CAT IV 600V.
* Max. hold (Max., Min. measuring value).
* 32 mm measuring conductor size.
* Auto power off.
* Type K Temp. probes TP-01, TP-02A, TP-03, TP-04, TP-05 are optional.

Specification
Display :39.5 mm x29.8 mm large LCD display
Measurement :DCV, ACV, DCA, ACA, Resistance, Capacitance, Frequency, Diode, Continuity beeper.
A/D counts no. :6000 counts.
Smart function :"V" function can select ACV, DCV automatically with auto range.
"Ω" function can select the Resistance, Diode, Continuity beeper, Capacitance automatically with auto range.
600A " " 1000A " function can measure ACA, DCA .
Data hold :To freeze the display reading on the LCD display
Power On/Off management:Auto power of or manual power off.
Hz button :When execute the voltage or current function also can measure the frequency of signal.
Selection Range :Smart function or auto function. manual range selecting.
Polarity :Automatic Switching, " - " indicates negative polarity.
Operating Temp :0 to 50 (32 to 122 )
Operating Humidity :Max. 80% R.H..
Power supply :DC 9 V battery 006P, MN1604
Power consumption :Approx. DC 9.1 mA
Max. Size :Conductor 32 mm (1.3 inch) Dia..
Dimension :241 x94 x 46 mm ( 9.5 x 3.7 x 1.8 inch ).
Weight :373 g/0.82 LB ( w/o battery ).
Accessories Included :Red and Black Test Leads 1 Set, Instruction Manual
Optional Accessories :Full line adapters :ACA/DCA current adapter,Tachometer adapter, Humidity adapter, Pressure adapter,Light adapter, EMF adapter, Sound level adapter, High voltage probe.

We do undertake Servicing and repairing of Lutron CM-6155F DCA/ACA CLAMP METER, Smart, 1,000 A lutron Range of products throughout india

Apart from supplying lutron Electrical Testing products in India through dealers network, catering to a variety of customers ranging from Atomic energy, Electricity Boards, Electrical Laboratory, Shopping Complexes, Shopping Mall, Electrical Contractors, Engineering Industries, Turnkey Construction Companies, Railways, Defence Installations, Research Laboratories, Educational Institutes and various Research and Development laboratories of leading national and multinational companies.

We DFT TECH, are lutron Authorized Distributors, Importers, Stockists, Dealers and Suppliers of Lutron CM-6155F DCA/ACA CLAMP METER, Smart, 1,000 A Products in Bagalkot, Bihar, Tiruvannamalai, Villupuram, Cuddalore, Dharwad, Delhi, Amristar, Tirupur, Vellore, Punjab, Chattisgarh, Jharkhand, Viruthachalam, Ambala, Dindugul, Chitoor and etc..
